Magnification of a lens is defined as the ratio of the height of the image to the height of the object. The images can be of two types. An image that can be obtained on a screen is called a real image. An image which cannot be obtained on a screen is called a virtual image.

**Real Image and Virtual Image**

Real image is that image which can be obtained on a screen. It is formed by the actual intersection of the refracted rays. It is usually formed by a convex lens.

Virtual image is that image which cannot be obtained on a screen. It is formed by the intersection of the rays. It is usually formed by a concave lens.

**Differences between Real Image and Virtual Image**

The major differences between real image and virtual image are:

**Magnification (m)**

The size of the image obtained by the lens depends upon the distance of the object from the lens. If the object is placed near the lens, the image is magnified and if the object is placed far from the lens, the image is diminished. Thus, we can define magnification of a lens as the ratio of a height of the image to the height of the object.

Mathematically,

Magnification = \(\frac {height\:of\:image\:(I)}{height\:of\:object\:(O)}\)

\(\therefore\) m = \(\frac IO\)

**Explanation:**

In the above figure, two triangles \(\triangle\)OCD and \(\triangle\)OAB formed are similar, since all the angles of two triangles are equal. We have: \(\frac {CD}{AB}\) = \(\frac {OC}{OA}\)

According to the definition of magnification:

Magnification = \(\frac {CD}{AB}\)

Or, m = \(\frac {distance\:of\:image\:from\:lens\:(v)}{distance\:of\:object\:from\:lens\:(u)}\)

i.e. m = \(\frac vu\)

Therefore, magnification is also calculated by the ratio of image distance (v) to object distance (u).

**Interpretation of Magnification**

- If magnification (m) is equal to 1 (m = 1), then the height of the image (I) is equal to the height of the object (O) i.e. I = O.
- If magnification (m) is less than 1 (m ˂ 1), then the height of the image is smaller than the height of the object.
- If magnification (m) is greater than 1 (m ˃ 1), then the image is larger than the height of the object.
- If magnification (m) is negative, the image is virtual and erected.
- If magnification (m) is positive, the image is real and inverted.

Hence, we can conclude that magnification shows how smaller or larger an image is than the object.

**To prove: \(\frac IO\) = \(\frac vu\)**

Let an object AB be placed on the principal axis of the convex lens and perpendicular to its principal axis beyond 2F. A ray BP is parallel to the principal axis passes through F after refraction through it and another ray BO passes undeviated through its optical center O. These two refracted rays PB’ and OB’ meet at B’. Hence, B’ is the real image of B, and A’B’ is the real image of AB.

In \(\triangle\)ABO and \(\triangle\)A’B’O, we have;

- \(\angle\)BAO = \(\angle\)B’A’O [\(\because\) both being 90⁰]
- \(\angle\)BOA = \(\angle\)B’OA’ [\(\because\) vertically opposite angles]
- \(\angle\)ABO = \(\angle\)A’B’O [\(\because\) remaining angles of each triangles]

\(\therefore\) \(\triangle\) ABO = \(\triangle\) A’B’O are similar.

Hence,

\(\frac {A’B’}{AB}\) = \(\frac {OA’}{OA}\)

i.e. \(\frac {height\:of\:image}{height\:of\:object}\) = \(\frac {image\:distance}{object\:distance}\)

\(\therefore\) \(\frac IO\) = \(\frac vu\) _{Proved.}

**Relation between Object distance, Image distance, and Focal length**

If u, v and f represent object distance, image distance and focal length of a lens respectively, we can give the relation between them by a formula:

\(\frac 1f\) = \(\frac 1u\) + \(\frac 1v\)

It is said to be lens formula.

For our simplicity, we take the real distance as positive and virtual distance is taken as negative. Hence, the focal length of convex lens is taken as positive and the focal length of concave lens is taken as negative.

- An image that can be obtained on a screen is said to be real image. It is always inverted.
- The image that cannot be obtained on a screen is said to be virtual image. It is always erect.
- Magnification of a lens can be defined as the ratio of height of the image to the height of the object. i.e. Magnification = \(\frac {height of image (I)}{height of object (O)}\)
- Magnification can also be calculated by the ratio of image distance (v) to object distance (u). Mathematically, Magnification = \(\frac {image distance (v)}{object distance (u)}\)
- Lens formula: \(\frac 1f\) = \(\frac 1u\) = \(\frac 1v\)

- It includes every relationship which established among the people.
- There can be more than one community in a society. Community smaller than society.
- It is a network of social relationships which cannot see or touched.
- common interests and common objectives are not necessary for society.

Magnification of image is defined as the ratio of height of the image to the height of the object. Mathematically,

m = \(\frac {height\:of\:image\:(I)}{height\:of\:object\:(O)}\)

Real image is defined as the image that can be obtained on a screen. It is formed by the actual intersection of the refracted rays in a convex mirror.

Virtual image is defined as the image which cannot be obtained on the screen. It is formed by the intersection of the rays in a concave mirror or lens.

S. No. |
Real Image |
S.No. |
Virtual Image |

1. | It is formed at that point where the refracted rays actually meet. | 1. | It is formed at that point where the refracted rays appear to meet. |

2. | It is always inverted. | 2. | It is always erect. |

3. | It is always formed on another side or behind the lens. | 3. | It is always formed on the same side where the object in the lens is. |

4. | Its size depends on the distance of the object from the optical centre of the lens. | 4. | Its size varies in concave and convex lens. It is larger in convex lens and smaller in concave lens. |

5. | It is obtained on a screen. | 5. | It cannot be obtained on screen. |
